Plastic Welding ApplicationRoofing

UNIROOF ST

The new UNIROOF ST roof welder combines closed-loop and open-loop and solves every problem close to the edge in a service-friendly way. Without converting.

หมวดหมู่: , , ป้ายกำกับ:
  • No retooling, thanks to movable transportation axle
  • Maintenance-free direct drive and open-loop technology
  • Ergonomic handling, flexible relocating and optimal machine guiding
  • 38% higher welding performance compared to similar machines

The new UNIROOF AT/ST roof welder is your flexible partner for welding thermoplastic roofing membranes on flat or pitched roofs (up to 30°). Thanks to its slim design and construction, as well as the movable transport axle, converting of the machine is no longer needed. Now, you can effortlessly weld close to the edge (to 100 mm / 4 inches) at the parapet or on the parapet and as easily in narrow circumstances. With 3450 W performance, 230 V and 15 Amps in the box, the UNIROOF AT/ST offers speedy top performance on any roof.

Technical Data

UNIROOF ST – 220-240 V / 3450 W / 40 mm / EU-plug

Attribute Unit Value
Voltage V~ 220 – 240
Power W 3450
Frequency Hz 50/60
Temperature °C 100 – 620
Air volume % 45 – 100
Speed m/min 1.0 – 10.0
Weld seam width mm 40
Size (L × B × H) mm 475 × 244 × 260
Weight (incl. cable and additional weights) kg 17.5
Material
Protection class I Protection Class I
Conformity mark CE Certification

UNIROOF ST – 230 V / 3450 W / 30 mm / EU-plug

Attribute Unit Value
Voltage V~ 220 – 240
Power W 3450
Frequency Hz 50/60
Temperature °C 100 – 620
Air volume % 45 – 100
Speed m/min 1.0 – 10.0
Weld seam width mm 40
Size (L × B × H) mm 475 × 244 × 260
Weight (incl. cable and additional weights) kg 17.5
Material
Protection class I Protection Class I
Conformity mark CE Certification

UNIROOF ST – 120 V / 1800 W / 40 mm / US-plug

Attribute Unit Value
Voltage V~ 120
Power W 1800
Frequency Hz 50/60
Temperature °C 100 – 620
Air volume % 45 – 100
Speed m/min 1.0 – 10.0
Weld seam width mm 40
Size (L × B × H) mm 475 × 244 × 260
Weight (incl. cable and additional weights) kg 17.5
Material
Protection class I Protection Class I
Conformity mark CE Certification



Downloads

General Catalogs :
GC – General Catalog Plastic Welding (12,92 MB)
BR – Accessories Hot air Hand Tools (3,63 MB)

Manuals :
BA – UNIROOF AT/ST TH (4,31 MB)
BA – UNIROOF AT/ST DE / GB / FR (5,52 MB)
QG – UNIROOF AT/ST (0,94 MB)

Brochures :
 BR – Roofing (2,86 MB)

VDO

Leister UNIROOF AT/ST roof welding close to the edge made easy
